Single Worktable Closed Type Metal Sheet & Tube Laser Cutting Machines
High Precision
With the most advanced laser head and control software , dacu laser cutting machine can easily meet your high percision needs no matter which kind of metal you are cutting.
BurrFree
With the most advanced laser head and fiber laser generators from Germany and China , the laser head can easily have enough output for the cutting needs. Therefore no matter how thick your meterail is , just select the right product ,then you can have the perfect cutting result.
High Speed
Enpowered by the the Fuji servo motor / Panasonic servo motor / SHIMPO reducer from Japan and HIWIN linear guide and YYC gear rack from Taiwan , our laser head can not only move accurately but also move really fast.
Features
Features
Swiss Made Laser Head
Rotary Knob type focus point adjustment for fine and flexible adjustment. Adjustable range: 20mm, accuracy: 0.05mm. Drawer type mirror seat to make protect glass replacing faster and easier.
Both collimating lens and focal lens could apply compound lens for optimal optical quality and cutting result. Modular design with optional collision-proof protective devices or pneumatic knife to realized swiftly switch between welding and cutting.
Optional magnetic collision-proof protective modular that would activate reliable separation and immediately light off in case of collision.
Other Key Components
Raycus Laser source has following features
1:Direct control of all the fiber laser functions;
2:Synchronized control of the laser source;
3:Overall power control and High speed perforation;
Driving System From Panasonic has following features:
1:Servo Motor with high precise;
2:Able to control cutting speed and position;
3:Stable running,lower speed without vibration phenomenon;
4:Better overload capacity
Shimpo Ruducer has following features:
1:Helical gear replacing previous spur gear,lower noice;
2:Back to the gap below 0.05 are points;
3:Low pulsating roration smooth
Rack and Pinion system from YYC has following features:
1: High hardness;
2: 6H precision;
3: easy to install.
Frame
Self Made High Quality Frame Is The Key Of Quality Control
Quality Control
Parameters of the machine
This is just a demo machine parameters. For more flexible configurations you can directly contact us.
| Parameter | Value |
|---|---|
| Laser Power(Option) | 1000W/1500W/2000W/2500W/3000W/4000W/6000W |
| Laser Medium | YVO4 |
| Laser Wavelength | 1070nm |
| Rated Output Power | 1000W |
| Beam Quality | <0.373mrad |
| X-axis Rout(Option) | 3000mm/4000mm/6000mm |
| Y-axis Rout(Option) | 1500mm/2000mm |
| Z-axis Rout | 120mm |
| X/Y-axis Positioning Accuracy | ≤±0.03mm/m |
| X/Y-axis Repositioning Accuracy | ≤±0.02mm/m |
| Max.Moving Speed | 120m/min |
| Max.Load | 1500KG |
| Phase | 3 |
| Rated Voltage | 380V |
| Power Frequency | 50Hz |
| Protection Level | IP54 |
Laser Parameters
This is the laser parameters of RFL-C3300. To know more laser head/source information you can directly contact us.
| Material | Thickness(mm) | Cutting Speed(m/min) | Gas Type |
|---|---|---|---|
| Stainless Steel | 1 | 25-40 | Nitrogen |
| 2 | 18-20 | Nitrogen | |
| 3 | 8-10 | Nitrogen | |
| 5 | 3-4 | Nitrogen | |
| 6 | 2.2-3 | Nitrogen | |
| 8 | 1.2-1.5 | Nitrogen | |
| Carbon Steel | 1 | 25-30 | Oxygen |
| 3 | 3.5-4.5 | Oxygen | |
| 6 | 2.2-2.8 | Oxygen | |
| 8 | 1.6-2 | Oxygen | |
| 10 | 1.1-1.4 | Oxygen | |
| 12 | 0.9-1.1 | Oxygen | |
| 14 | 0.8-0.9 | Oxygen | |
| 16 | 0.7-0.8 | Oxygen | |
| 18 | 0.65-0.7 | Oxygen | |
| 20 | 0.55-0.65 | Oxygen | |
| Aluminum | 1 | 25-40 | Nitrogen |
| 3 | 8-10 | Nitrogen | |
| 6 | 1.6-2 | Nitrogen | |
| Brass | 1 | 25-35 | Nitrogen |
| 2 | 12-15 | Nitrogen | |
| 3 | 6-8 | Nitrogen | |
| 4 | 3-4 | Nitrogen | |
| Copper | 1 | 15-20 | Oxygen |
| 2 | 8-10 | Oxygen |
